The REAL-EL RS-6 EXTRA surge protector is designed for connection of electrical appliances to the electrical network and their protection against high-voltage surge pulses and permanent filtration of high-frequency noises.
The REAL-EL RS-6 EXTRA surge protector is designed for connection of electrical appliances to the electrical network and their protection against high-voltage surge pulses and permanent filtration of high-frequency noises.
- Features
- Specifications
- Support
- Double-pole power switch with built-in fuse аnd LED
- Individual switches for every socket
- 6 grounded sockets with protection shutters
- Resettable fuse does not require replacement
- Pure copper cable without alloys
Rated voltage, V
~230
Operating frequency, Hz
50
Total power of connected load, W
2300
Load peak current, А
10
Maximum energy absorption of pulse interference, J
350
Input plug type
1 × CEE 7/7
Output sockets type
6 × CEE 7/3
Master switch of sockets
double-pole power switch
Cable length, m
1.8; 3.0; 5.0
Case material
ABS plastic
Dimensions, mm
330 × 40 × 70
Color
black
Life time
2 years
- rs-6extra_manual_en.pdf (99 КБ)
