The REAL-EL STAB-500 automatic voltage regulator is designed for providing various equipment with high-quality stable electric power supply in conditions of significant and continuous deviations of mains voltage and protecting consumer devices against overload, against influence of high-frequency and impulse interferences.
The REAL-EL STAB-500 automatic voltage regulator is designed for providing various equipment with high-quality stable electric power supply in conditions of significant and continuous deviations of mains voltage and protecting consumer devices against overload, against influence of high-frequency and impulse interferences.
- Features
- Specifications
- Support
- LED Display
- Toroidal transformer with automatic overload protection
- Delay of switching on 6 sec
- Zero-cross switching technology
- Microprocessor control
- Maximum protection against high voltage, low voltage, short circuit, overheating and overload
Input terminals
1 × СЕЕ7/7
Input socket
1 × СЕЕ7/4
AVR type
relay
Output power, VA
500
Maximal output power, W
400
Maximum load, W
400
Input voltage level, V
~140 – 260
Output voltage level, V
~220 ± 10 %
Frequency, Hz
50
Protection
against high voltage, low voltage, short circuit, overheating and overload
Typical switching time, ms
≤ 10
Indication
inpur and output voltage
Fuse
5 А
Environmental temperature, °С
0 ~ +40
Relative humidity, %
up to 90
Case material
metal + plastic
Dimensions, mm
170 × 125 × 190
Weight, kg
1.9
Color
black
Life time
5 years
- REAL-EL_AVR_STAB-500M_manual_eng.pdf (186 КБ)
